Cudy Wr1200E Ac1200 Gigabit Wi-Fi Router, Mu-Mimo, Beamforming

32,50 €

Λεπτομέρειες:

ΕΙΔΟΣ	AP/ROUTER
ΛΕΙΤΟΥΡΓΙΑ MESH	ΟΧΙ
ΡΥΘΜΟΣ ΜΕΤΑΔΟΣΗΣ ΔΕΔΟΜΕΝΩΝ	AC1200Mbps
ΣΥΧΝΟΤΗΤΑ	DUAL BAND (2.4 + 5 GHz)

CPU	Chipset	MT7628
	CPU Details	580 MHz Single-Core, MIPS24KEC

Memory/Storage	Flash/ROM	8 MB (64 Mbit ) NOR
	DDR/RAM	64 MB (512 Mbit) DDR2

Wireless	5 GHz Wi-Fi Speed	867 Mbps
	2.4 GHz Wi-Fi Speed	300 Mbps
	5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	Wi-Fi Antennas	2× Fixed
	5 GHz Antenna Gain Max	4.93dBi
	2.4 GHz Antenna Gain Max	3.49dBi
	FEM or PA/LNA	5 GHz: 2× Internal
		2.4 GHz: 2× Internal

	Beamforming	TRUE
	Range Performance	Max: 170 m (558 ft)
		Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
	Wall Performance	Two wooden walls with thickness < 10 cm (4)
		One concrete wall with thickness < 20 cm (7)

Interfaces	10/100 Mbps RJ45 Ports	4
	Ethernet Notes	1× WAN port, the rest are LAN ports
	LED	System
	Physical Buttons	WPS Button
		Reset Button

	Power Input	DC Jack

Power	Power Methods	DC
	DC	12V 1A
	Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC
		Output: 12V 1A DC
	Max Power Consumption (W)	8W
	Idle Power Consumption (W)	3W

Reliability	Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
		Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
		Humidity: 10% ~ 90% non-condensing
		Storage Humidity: 5% ~ 95% non-condensing


Certifications	FCC, CE

Mechanical	Installation	Desktop
	Dimension	118×80×27.5 mm
		4.65×3.15×1.08 inches

Wireless	Wi-Fi Standards	Wi-Fi 5
	Max Wi-Fi Modulation	256-QAM
	Wi-Fi Efficiency	MU-MIMO
	Wi-Fi Efficiency Note	MU-MIMO available on 5 GHz
	Max Capacity	128
	Recommended Client Upper Limit	40
	Max Wi-Fi Channel Width	80 MHz
	Wi-Fi Security	WPA/WPA2/WPA3
	Guest Network	2.4 GHz, 5 GHz
	WPS	TRUE

General	Operation Modes	Wi-Fi Router
		Access Point
		Range Extender
		WISP
		Client

	WAN Mode	DHCP
		Static IP
		PPPOE
		PPTP
		L2TP

	Internet Failover Sequence	WAN
		WISP


Network	QoS	Per-User Rate Limiting
	DHCP	Address Reservation
		DHCP Client List
		Server

	IP Versions	IPv4/IPv6
	IPv6 Protocols	Relay
		Dynamic (SLAAC/DHCPv6)
		Static (Fixed IP)
		Passthrough
		464XLAT
		MAP-E
		DS-Lite

	IPTV/VLAN	Bridge
		Tag VLAN
		VoIP VLAN
		IPTV VLAN

	TTL Customization	Extend
		Spoof
		Custom

	IGMP	IGMP Proxy
		IGMP Snooping

	Forwarding	Port Forwarding
		Port Triggering
		UPnP
		DMZ

	Firewall	SPI Firewall
		DoS Protection
		Block PING

	Application Layer Gateway	IPSec Passthrough
		L2TP Passthrough
		PPTP Passthrough
		FTP Passthrough
		TFTP Passthrough
		H323 Passthrough
		SIP Passthrough
		RTSP Passthrough


Utilities	VPN Client	OpenVPN
		Wireguard
		PPTP
		L2TP

	DNS Options	Manual DNS
		Rebind Protection
		Override Clients DNS

	Wake on LAN	TRUE
	Online Detection	TRUE

Management	All Devices Management	Wi-Fi Time Schedule
		MAC Filter
		IP/MAC Binding

	Per-Devices Management	Internet On/Off
		VPN On/Off
		Online Time Schedule
		Device Rename

	Content Management	Domain Filter
		IP Filter


System	LED Control	TRUE
	Local Control Method	Config Web Page
		App Control

	Remote Control Method	TR069/TR098/TR111/TR181
		Config Page via HTTP

	Firmware Upgrade	Local Update
	Reliability	Timed Reboot
		Backup and Restore

	Diagnostic Tools	Diagnosis
		Ping
		Traceroute
		NSLookup
		System Log

	Languages	English
		German
		Spanish
		French
		Hebrew
		Italian
		Portuguese
		Ukrainian
		Russian
		Korean


Dashboard	Panel	Internet Status
		Devices Management
		WAN Status
		LAN Status
		WISP Status
		Wi-Fi Status
		VPN Status
		DHCP Server Status
		System Version

	Charts	Internet Speed
		WISP Speed
		Wi-Fi Speed
